The EK-CH16 series adopts a brand new surging processor, equipped with an Android embedded system, advanced SDR technology and super protocol stack, making images clearer, with lower latency, longer distance, and stronger anti-interference ability. It supports HDM, network port, sensor interface dual serial port transmission, s.bus and other rich interfaces, which can be applied to drones, robots, industrial control equipment, fire protection, power, and other fields.
The EK-CH16 series adopts a brand new surging processor, equipped with an Android embedded system, advanced SDR technology and super protocol stack, making images clearer, with lower latency, longer distance, and stronger anti-interference ability. It supports HDM, network port, sensor interface dual serial port transmission, s.bus and other rich interfaces, which can be applied to drones, robots, industrial control equipment, fire protection, power, and other fields.
| Remote control parameters | |||
| Model | H16 | Number of channels | 16 |
| Working voltage | 4.2V | RF power | 20DB@CE/23DB@FCC |
| Frequency band | 2.400-2.483Ghz | Frequency hopping | New FHSS frequency hopping |
| Upgradation | App online upgrade | Weight | 1034g |
| Size | 272*183*94mm | Battery | 20000mA/H |
| Endurance | 6-20h | Charging interface | TYPE-C |
| Application | Helicopters, fixed wings, multi rotors, vehicles and ships | ||
| Receiver parameters | |||
| Model | R16 | Number of channels | 16 |
| Working voltage | 7.2-72V | RF power | 20DB@CE/23DB@FCC |
| Size | 76*59*11mm | Weight | 90g |
| Three body MIPI camera | |||
| Model | MIPI | Working current (with lights on) | 140mA |
| Working voltage | 14-72V | Working current (without lights on) | 14mA |
| Size | 102.1*42.6*36.5mm | Weight | 55g |
The main purpose and scope of application are for remote control operation of helicopters, fixed wings, multi rotors, vehicles, ships, etc. for video image transmission (with optional cameras), data transmission, and control of drone flight.
