Flexible mechanical claws can adapt to different shapes of objects to achieve flexible grasp, including more fragile objects, such as eggs, acrylic claw is suitable for grabbing balls with a diameter of 20-80mm or so. The two products have a wide range of adaptation, and the rotary mode operating environment has been consistent with the control environment.
| Product name | EK-R-80 Flexible Mechanical Claw | EK-R-100 Acrylic claw |
| Material | Aluminum alloy + glass fiber | Acrylic + copper column |
| clamping range | 0-80mm | 0-90mm |
| maximum clamping force | 1000g | 800g |
| Steering gear Model | PD-15D/SP-15D | PD-15S/PD-20S/SP-15S/SP-20S |
| Rotation mode | gear + connecting rod | |
| Operating environment | normal temperature and pressure | |
| Size | 128*105*70mm | 80*61*70mm |
| Weight | 158g (including intelligent steering gear) | 170g (including intelligent steering gear) |
| Control mode | PWM pulse/serial control | |
